Hitch Weight
969 lb.
9,999 lb.
8,023 lb.
1,976 lb.
Exterior Length
35' 9"
Exterior Height
12' 0"
Exterior Width
Fresh Water
50 gal.
Gray Water
80 gal.
Black Water
35 gal.
Awning Size

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.

  • Construction & Exterior Features

    • 5/8" Tongue and Groove Floor Decking
    • AlphaPly Roof Membrane with Limited Lifetime Warranty
    • Extra-Large Full Pass Through Storage (Per Floorplan)
    • Power Patio Awning
    • Safety Glass Windows
    • Cambered Powder Coated I-Beam Chassis
    • 60K BTU Tankless Water Heater
    • Aluma Frame Fiberglass Sidewalls (STD on View Series)
    • Water Heater Bypass
    • 2" Wall Construction, 16" (or less) on Center
    • Triple Seal Slide Out System
    • Flush Floor Electric Slide Out (per FP)
    • Swing Arm Entry Assist Handle
    • Two Marine Grade Exterior Speakers
    • Aerodynamic Front Radius Profile
    • Smooth .40 Mil Aluminum Front Wrap
    • Easy Lube Axles w/Self Adjusting Brakes
    • One Piece Vinyl Floor
    • R-7 Fiberglass Insulation Throughout
    • Textured Rockguard
    • Hurricane Straps
    • LP Quick Disconnect
    • Power Awning w/adjustable legs
    • 7-Way Cord Holster
    • LED Awning Light Strip
  • Kitchen Features

    • New Shaker Style Cabinet Doors
    • 10 cu. ft. 12V Refrigerator
    • Microwave w/ carousel
    • Black High Rise Spring Faucet
    • Residential Style Under Mount Kitchen Sink and Flush Mount Sink Covers
    • 3-Burner, High Output Range w/Oven
    • Full Extension Ball Bearing Drawer Guides
    • Shelving in Overhead Cabinets in the Kitchen
    • Large Pots and Pans Storage Under Dinette (Per Floorplan)
    • Therma Foil Countertops
  • Living Room Features

    • 80" Interior Height
    • Ducted 15K A/C Roof Air Conditioner
    • VersaLounge Sofa & Dinette (per FP)
    • 30" Fireplace
    • Digital Antenna w/Booster
    • 2-Zone Soundbar, FM, Bluetooth, HDMI Playthrough
    • 30K BTU Suburban Forced Air DSI Furnace w/Digital Thermostat
    • In-Floor Ducted Heat
    • Cable TV Hookup Living Room and Bedroom
    • Dimmer Switch for LR OH Lights
  • Bedroom Features

    • Capital Bedding in Primary Bedroom
    • VersaTilt Bed
    • Bedside 110 Volt Power Outlets (2)
    • Bedside USB Chargers (2)
    • Solid Bedroom Privacy Door (Per Floorplan)
    • Laundry Hamper and bag (per FP)
  • Bathroom Features

    • 12 Volt Power Bath Roof Exhaust Fan
    • Foot Flush Toilet
    • High Definition Countertops
  • Security & Safety Features

    • LP Leak Detector
    • Smoke Detector
    • Carbon Monoxide Detector
    • Fire Extinguisher
    • Welded Heavy Duty Safety Chains
    • Electric Full Self-Adjusting Brakes
    • GFI Receptacles
    • ANSI 119.2 Certified
    • Meets ALL National Highway Administration Specs
    • RVIA Approved Product
  • Popular Options

    • 50 Amp Service w/ Bedroom A/C Prep
    • 40" LED Smart TV Living Area
    • Arctic Pkg - Radiant Foil Insulation Roof & Floor
    • Production Change Fee
    • RVIA Seal - Mandatory
    • Alum Framed Fiberglass Sides (per FP)
    • Dual 30# LP Bottles (IPO 20#)
