Hitch Weight
775 lb.
7,775 lb.
6,353 lb.
1,422 lb.
Exterior Length
32' 10"
Exterior Height
10' 10"
Exterior Width
Fresh Water
50 gal.
Gray Water
65 gal.
Black Water
30 gal.
Awning Size

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.

  • Cruise Lite West Standard Features

    • Ladder Prep
    • AlphaPly Roof Membrane with Limited Lifetime Warrant
    • VersaLounge- per floorplan
    • Versatilt Bed in Primary Bedroom
    • Fully Walkable Roof
    • 200W solar w regulator
    • Inverter Prep
    • Solid Entry Step
    • Dimmer Switch
    • Aerodynamic Front Profile
    • Shaker Style Cabinet Doors
    • 3-Burner Cooktop
    • 13.5 Air Conditioner (Ducted per FP)
    • Solar Prep on Chassis
    • Laundry Bag and Totes (per FP)
    • LP Quick Disconnect
    • Digital TV Antenna w/Booster
    • (2) Gas Struts Under Main Bed
    • Larger Tables at U-Dinette
    • (2) Exterior Speakers
    • (2) 20 lb. LP Bottles w/Hard Cover
    • 60K BTU Tankless Water Heater
    • 50gal Fresh Water
    • Microwave w/ carousel
    • Ball Bearing Drawer Guides
    • Pass Through Storage (Per Floorplan)
    • Therma Foil Countertops
    • 78" Interior Height
    • Easy Lube Axles w/Self Adjusting Brakes
    • 30K BTU Suburban Furnace
  • Cruise Lite West Popular Options

    • 15K AC
    • Radiant Foil
    • Dual 30# Tanks IPO 20# tanks
    • Comfort and Convenience Package (Mandatory)- Battery Disconnect, Black Tank Flush, cable/satellite ready, Spray Port, Foot Flush Toilet, Range with Oven, Skylight Over Tub, Spare Tire and Carrier, Sink Covers, Power Tongue Jack, Teddy Bear Bunk Mats
    • Best In Class Value Package (Mandatory)- Roller Shades throughout, Power Awning, LED Awning Light Strip, LED "Power Savings" Interior light Package, Recessed Glass Cooktop, Bluetooth Stereo with FM &HDMI, Back up Camera Prep, Friction Hinge Doors with Magnetic Door Latches, 7 way Plug Holster
