Hitch Weight
330 lb.
4,730 lb.
2,964 lb.
1,766 lb.
Exterior Length
19' 6"
Exterior Height
10' 5"
Exterior Width
Fresh Water
42 gal.
Gray Water
22 gal.
Black Water
22 gal.
Awning Size

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.

  • GOAT Edition Features (157FBGT, 175BHGT, 176BQGT Only)

    • GOAT PACKAGE-335W Solar w/40 amp MPPT Controller, 2000W Inverter, X-Comp Gladiator Tires, Enclosed Underbelly, 4.5cu ft 12V Refrigerator, 20K BTU Furnace, 2- 30# LP Bottles
    • Power Awning w/LED Light Strip
    • 5/8” Tongue and Groove Plywood Floor
    • Alphaply Roof Membrane with Limited Lifetime Warranty
    • Fully Walkable Roof
    • Solid Entry Steps (Main Entry)
    • Bluetooth Stereo with Remote
    • Back up Camera Prep
    • Solar Prep
    • USB Ports
    • Friction Hinge Entry Door
    • Roller Shades Throughout
    • Spare Tire & Carrier
    • Stabilizer Jacks (2 rear)
    • Battery Disconnect
    • Black Tank Flush
    • Skylight Over Tub
    • Cable Satellite Ready
    • Tongue Jack
    • TV Antenna w/Booster
    • 2 Burner Cooktop
    • 4.5 cu ft Double Door Electric Refrigerator
    • Single Bowl Kitchen Sink
    • 13,500 Roof Mount A/C (Non-Ducted)
    • 60K BTU Tankless Water Heater
    • 40–42-gal Fresh Water (per F/P)
    • Teddy Bunk Mats (per F/P)
    • Radius Front Profile w/Rock Guard
    • Water Heater By-Pass & Winterized
    • Outside Speakers
    • LP Quick Disconnect
    • Radial Tires
    • LED "Power Saver" Interior Lighting
    • Optional Microwave w/ carousel
